Combo Scan Kiosk ID scanner

Self-service ID verification in ultra-compact form, under 2 seconds

Overview

Smooth passenger flow and easy self-service operation – that’s what Combo Scan Kiosk is made for. This scanner extracts personal data from identity documents like passports, visas or ID cards within 2 seconds. As the name ‘kiosk’ suggests, integration with self-service kiosks, e-gates or vending machines is easy: due to the scanner’s low profile, ultra-compact rectangular form and mounting holes. All of these come with a clever design which includes no moving parts, to offer a truly maintenance-free operation.

This ID scanner allows intuitive usage, greatly improving passenger access or customer handling in those applications where checking identity documents is a must but there is no human staff attendance – especially in CUSS systems like airport e-gates, bank ATMs, self-service check-in kiosks and even vending machines where usage is restricted by age.

Highlighted features

Coverless-design

Ultra-compact

Optical quality is maximized in the smallest possible volume, making it easy to integrate in any hardware.

Ultra-compact

Coverless design

The innovative Adaptive Light Control feature lets the scanner work flawlessly even with strong external light being present.

MRZ-reading

MRZ reading

The scanner’s wide surface allows the reading of MRZ even from the ID-3 size passports.

USB-powering

Single USB powering

Steady operation even in such environments where there is no external power – a single USB is enough.

Metal-casing

Metal casing

A strong, durable and IP53-rated metal case protects the optical unit for long-term usage..

Document-placement-guide

Document placement guide

Having the added document guide on top, users cannot do the scanning wrong.

Adaptive Light Control for high performance ID verification

Imaging is enhanced by our unique Adaptive Light Control feature, which secures steady operation even in environments with extreme light conditions. The software automatically detects and filters ambient light sources out to provide a flawless scanning performance. This is crucial both for accurate OCR and reliable authentication results.

self-service market statistics

About the self-service market

The self-service and automation market is one of the fastest growing sectors in the world: it’s expected to double in size in the next 5 years (prediction for 2024 using data and trendline from 2019).

Minimum volume for maximum integratibility

When designing this device, our developers have two main aspects in mind: to make the unit as compact as possible by reducing its size, while keeping our high standard for optical quality. In this tiny volume, Combo Scan Kiosk has a built-in optical unit with a mirror, infrared and visible illumination LEDs, controller and power unit, all in a full metal enclosure to provide extended durability.

Application areas

atm

ATMs

Check-in-kiosks

Check-in kiosks

e-gates

E-gates

Access-control-turnstiles

Access control turnstiles

Vending-machines

Vending machines

Video

Request information

Combo Scan Kiosk ID scanner (1)

  • This field is for validation purposes and should be left unchanged.

Get more information or get a quote.

Our sales & product experts are here to help you. Contact us or find a prime partner near to your location.

View our representatives on a map

Specifications

Product main feature 1 Ultra compact, USB-powered ID scanner
Product main feature 2 Ideal for integration with kiosks, eGates
Type of installation Integrated / built-in
Illumination sources Visible white (430-700nm), Near IR B900
Active scan area 125 mm × 55 mm (4.92" × 2.17")
Supported document types Passports, ID cards, Visas, Driver's licenses, 1D & 2D barcodes
Provided images Visible (normal), IR, OVD image, Glare-free image
OCR reading capability ICAO compliant documents per ICAO 9303 specification Part 1, Part 1v2, Part 2, Part 3 and Part 3v2 for Type ID-1, ID-2 and ID-3 MRZ Optical Character Recognition, One line Driving Licenses per ISO18013 part 2 specification
Barcode reading capability 1D barcodes (2 of 5 interleaved, 2 of 5 industrial, Code 128, Code 39, EAN-8 and EAN-13), 2D barcodes used on BCBP and other documents (PDF 417, QR Code®, DataMatrix™ and Aztec formats) from paper documents and many mobile devices, AAMVA compliant PDF417 and IATA BCBP
Document authentication B900 ink check, Expiry date check, MRZ checksum validation, Data consistency checks: MRZ vs. VIZ vs. Bar codes IR B900 check, Automated, document specific security pattern verification (optional)
Software development kit (SDK) C/C++, C#, Delphi, Java, VB.NET, Visual Basic 6.0
Included in the SDK Demo applications, Sample programs in source code
General interfaces Twain
Human interface Three programmable status LEDs (yellow, red, green)
Supported Operating Systems Windows and Linux (32/64 bit)
Communication USB2.0 high speed
Scanning window glass 4 mm thick hardened glass
Power supply From USB, no need for external power source
Regulatory CE (EMC), EU WEEE, REACH & RoHS Directive, FCC Part 15 Class A
Dimensions 125 mm × 123 mm × 58.5 mm (4.92" × 4.84" × 2.3")
Weight 0.6 kg (1.32 lbs)
Operating temperature 5°C - +45°C (+45°F - +113°F)
Warranty 3 years
