Intellio Initio Dome Vario Focus CCTV camera

Vandal-proof dome camera with zoom and IR for night vision

Overview

With our new Initio series, we jump to the next episode of CCTV surveillance. These cameras have onboard detectors to automatically identify specific events like intrusion or tripwire crossing powered by integrated AI technology.

This dome camera offers various advantages for your security system. Firstly, it’s a robust and vandal-proof surveillance solution thanks to the IP67 and IK10-rated construction. It also delivers high-quality imaging by the new 4-megapixel sensors paired with 2.8 – 12 mm varifocal-lens. It is equipped with a long-range night vision even up to 40 meters, powered by powerful infrared illumination, for nighttime or low-light environments. And it provides smooth operation for both indoor and outdoor locations.

By using this CCTV camera, you are supported by three years of manufacturer’s warranty, ensuring a long-term solution for any surveillance task.

Highlighted features

Zoom

Zoom

The 2.8-12 mm varifocal lens allows you to set the zoom during the initial setup, providing a crisp video feed.

intellio-initio-dome-vario-v3-vandal-proof-design

Vandal-proof design

The camera endures physical shocks thanks to its IP67 and IK10 compliance.

Night-vision

24/7 mode

See what’s happening during the day and also in the night up to 40 meters (with IR illumination).

Onboard-analytics

Onboard analytics

The built-in line crossing and intrusion detection make Initio Dome V a truly smart camera.

Integrated-storage

SD card data storage

Insert your SD card into the slot so the camera saves the valuable recording even if there is a network outage.

3years-warranty

3 years warranty

Expect no failure due to the lack of moving parts - plus, you are backed up with 3 years of manufacturer warranty.

Specifications

Product main feature 1 Indoor & outdoor, vandal-proof camera with varifocal lens
Product main feature 2 On-board analytics, IP67 protection, 40m IR range
Camera design Dome
Lens Varifocal
Resolution 4 MP
Day & night Yes
Image sensor 1/3" Progressive Scan CMOS
Minimum illumination Color: 0.005 lux (F1.6, AGC ON), 0 lux with IR
Shutter speed 1/3 s - 1/100,000 s
Wide dynamic range (WDR) 120 dB
Focal length 2.8 mm - 12 mm
Field of view (FOV) Horizontal: 95.8° - 29.2°, Vertical: 50.6° - 16.4°
Resolution of sensor(s) 2688 x 1520
Streaming (Primary & Secondary) 50Hz: 25fps (2688 × 1520, 1920 × 1080, 1280 x 720) & (640 × 480, 640 × 360), 60Hz: 30fps (2688 × 1520, 1920 × 1080, 1280 x 720) & (640 × 480, 640 × 360)
Day/night switch Day / Night / Auto / Schedule
Video compression H.265 / H.264 / MJPEG (only on Secondary stream)
Video bit rate 256 Kbps - 8 Mbps
Audio compression G.711ulaw / G.711alaw / G.722.1 / G.726 / MP2L2 / PCM / MP3 / AAC
Communication interface 1x RJ45 10M/100M Ethernet port
I/O port Alarm I/O, Audio I/O
On-board storage Built-in microSD slot, up to 256 GB
Communication protocols 802.1X, Bonjour, DDNS, DHCP, DNS, FTP, HTTP, HTTPS, ICMP, IGMP, IPv6, NTP, PPPoE, QoS, RTP, RTSP, SMTP, SSL/TLS, TCP/IP, UDP, UPnP
Client IVS 5
IR illumination distance 40m (131 ft)
Wavelength 850 nm
Operating conditions -30 °C to +60 °C (-22 °F to +140 °F), Humidity 95% or less (non-condensing)
Power supply/Consumption 12 VDC / 0.88A, max. 10.5W, PoE (802.3af, 36V - 57V), 0.35A - 0.22A, max. 12.5W
Ingress protection IP 67
Impact protection IK 10
Dimensions 153.3 mm x 111.6 mm (6.1" x 4.4")
Weight 880 g (1.94 lbs)
Built-in intelligence Line crossing & Intrusion detection - with human and vehicle targets classification
Junction box Yes
